Before you can implement ThickBox make sure the page that invokes ThickBox has a valid DTD. This is required for ThickBox to look and function correctly.
1. ThickBox requires the jQuery JavaScript library; because of this, you will need to include the jquery.js file in the head element of your web page, followed by the thickbox.js file (NOTE: jquery.js must come first in the source order). Example below:
Once you have included the .js files, open thickbox.js or thickbox-compressed.js and locate the tb_pathToImage variable at the top of the page. Once you have found it, make sure to change the value of tb_pathToImage to the path where the loadingAnimation.gif file is located on your own server.
2. Include the ThickBox CSS file in your web page. As of version 3.1 you will
also need to update the path to the macFFBgHack.png in the thickbox.css
file. Example options below:
Or, open the thickbox.css file
and copy and paste the styles into an existing style sheet. Be
aware that the ThickBox CSS file will remove the browsers default
padding and margin for all elements.
3. View the examples to learn the many different ways to use and invoke ThickBox functionality.
Supported & Tested Browsers
Windows IE 6.0, Windows IE 7+, Windows FF 2.0.0.6+, Windows Opera 9.0+,
Macintosh Safari 2.0.4+, Macintosh FF 2.0.0.6+, Macintosh Opera 9.10+
This example is exactly like the single image functionality except that
it allows use of the rel attribute to group images together so they can
be navigated in a ThickBox. The ideal usage would be for images
galleries.
Instructions:
Create a link element (<a href>)
Give the link a class attribute with a value of "thickbox" (class="thickbox")
Provide a path in the href attribute to an image file (.jpg .jpeg .png .gif .bmp)
Give each link element the same rel element and value. (Example: rel="gallery-plants")
Important to Remember:
While
you have a ThickBox gallery image open, you can navigate forward and
backward through the images by using the left < key (previous) and
right > key (next) on the keyboard (Next and Previous links are also
provided in the ThickBox). The images will appear in the gallery from
first to last as they appear in the HTML document flow.
Click An Image:
<a href="images/plant1.jpg"title="add a caption to title attribute / or leave blank"class="thickbox"rel="gallery-plants"><img src="images/plant1_t.jpg"alt="Plant 1" /></a>
<a href="images/plant2.jpg"title="add a caption to title attribute / or leave blank"class="thickbox"rel="gallery-plants"><img src="images/plant2_t.jpg"alt="Plant 2" /></a>
<a href="images/plant3.jpg"title="add a caption to title attribute / or leave blank"class="thickbox"rel="gallery-plants"><img src="images/plant3_t.jpg"alt="Plant 3" /></a>
<a href="images/plant4.jpg"title="add a caption to title attribute / or leave blank"class="thickbox"rel="gallery-plants"><img src="images/plant4_t.jpg"alt="Plant 4" /></a>
Change the values of height and width in the query accordingly
Optionally you may add modal=true to the query string (e.g. ?KeepThis=true&TB_iframe=true&height=400&width=600&modal=true) so that closing a ThickBox will require calling the tb_remove() function from within the ThickBox iframe (self.parent.tb_remove()). See the iframe demo for an example, where you must click "ok" to close the ThickBox.
Important to Remember:
Add all other query parameters before the TB_iframe parameters. Everything after the "TB" is removed from the URL.
<a href="ajax.PHP?keepThis=true&TB_iframe=true&height=250&width=400" title="add a caption to title attribute / or leave blank" class="thickbox">Example 1</a>
<a href="ajaxOverFlow.htm?keepThis=true&TB_iframe=true&height=300&width=500" title="add a caption to title attribute / or leave blank" class="thickbox">Example 2</a>
<a href="iframeModal.html?placeValuesBeforeTB_=savedValues&TB_iframe=true&height=200&width=300&modal=true" title="add a caption to title attribute / or leave blank" class="thickbox">Open iFrame Modal</a>
Use a hidden HTTP request (AJAX) to fetch files from the same server and have ThickBox display the contents of the files.
Instructions:
Create a link element (<a href>)
Give the link a class attribute with a value of thickbox (class="thickbox")
Provide a path in the href to the file/directory on the server. (href="ajaxLogin.htm")
In the href attribute, after the URL path to the file, add the following query on to the end of the URL:
?height=300&width=300
Change the values of height and width in the query accordingly
Optionally you may add modal=true to the query string (e.g. ?height=300&width=300&modal=true) so that closing a ThickBox will require calling the tb_remove() function from within the ThickBox. See the login example, where you must click cancel to close the ThickBox.
Important to Remember:
In order to open new Ajax content in an open Ajax ThickBox, its code must also contain the appropriate HTML (class=""thickbox) to launch an Ajax ThickBox (see demo for example). The only catch is, the ThickBox calls must include both the width and height of the original ThickBox. If you leave it blank the window will resize to the default size(630x440).
<a href="ajaxOverFlow.html?height=300&width=300" title="add a caption to title attribute / or leave blank" class="thickbox">Scrolling content</a>
<a href="ajax.PHP?height=220&width=400" class="thickbox" title="add a caption to title attribute / or leave blank">No-scroll content</a>
<a href="ajaxLogin.html?height=85&width=250&modal=true" class="thickbox" title="Please Sign In">login (modal)</a>
<a href="ajaxTBcontent.html?height=200&width=300" class="thickbox" title="">Update ThickBox content</a>
